Externally Controlled In Situ SEM: Multi-Rate Scanning With Signal Regulation and Spatiotemporal Fusion.

Jieping Ding1, Ling'en Liu1, Ni Wang2

  • 1School of Materials Science and Engineering, Beijing University of Technology, Beijing, China.

Microscopy Research and Technique
|June 11, 2026
PubMed
Summary
This summary is machine-generated.

High-temperature in situ scanning electron microscopy (SEM) imaging is improved by a new system that reduces thermal electron noise. This rapid scanning approach enhances image quality and speeds up data acquisition for materials analysis.

Keywords:
image enhancementimaging systemin situ SEMmulti‐rate scanning

More Related Videos

In vivo Imaging of Biological Tissues with Combined Two-Photon Fluorescence and Stimulated Raman Scattering Microscopy
09:06

In vivo Imaging of Biological Tissues with Combined Two-Photon Fluorescence and Stimulated Raman Scattering Microscopy

Published on: December 20, 2021

Related Experiment Videos

Last Updated: Jun 13, 2026

Implementation of a Nonlinear Microscope Based on Stimulated Raman Scattering
09:13

Implementation of a Nonlinear Microscope Based on Stimulated Raman Scattering

Published on: July 6, 2019

In vivo Imaging of Biological Tissues with Combined Two-Photon Fluorescence and Stimulated Raman Scattering Microscopy
09:06

In vivo Imaging of Biological Tissues with Combined Two-Photon Fluorescence and Stimulated Raman Scattering Microscopy

Published on: December 20, 2021

Area of Science:

  • Materials Science
  • Microscopy
  • Engineering

Background:

  • In situ scanning electron microscopy (SEM) is vital for studying material properties at high temperatures.
  • High-temperature environments introduce thermal electrons and noise, distorting SEM images and hindering analysis of phase transitions and deformations.

Purpose of the Study:

  • To develop an advanced in situ image acquisition system to overcome image distortion caused by thermal electrons and noise in high-temperature SEM.
  • To improve the quality and speed of high-temperature SEM imaging for dynamic microstructure characterization.

Main Methods:

  • Implemented an externally controlled in situ image acquisition system featuring multi-rate scanning to minimize thermal electron interference.
  • Incorporated a dual-stage signal regulator to counteract signal attenuation during high-speed scanning.
  • Integrated an image fusion algorithm for effective noise suppression while preserving image details.

Main Results:

  • The system successfully acquired high-quality SEM images at 1050°C with an acquisition time of 1.5 seconds, significantly faster than traditional systems (3.5 seconds).
  • Synthesized images showed improved Structural Similarity Index (SSIM) and reduced Noise Quality Index (NIQE) between 900°C and 1050°C compared to conventional speeds.
  • Demonstrated reliable technical support for dynamic microstructure characterization of high-temperature materials.

Conclusions:

  • The developed hardware-algorithm solution effectively mitigates thermal electron noise and signal attenuation in high-temperature SEM.
  • This advancement enables high-quality, rapid in situ imaging, promoting SEM applications in extreme environments for materials research.
