Monolithic Tandem Vertical Electrochemical Transistors for Printed Multi-Valued Logic.

Dong Un Lim1,2, Sae Byeok Jo3,4, Jeong Ho Cho1

  • 1Department of Chemical and Biomolecular Engineering, Yonsei University, Seoul, 03722, Republic of Korea.

Advanced Materials (Deerfield Beach, Fla.)
|December 9, 2022
PubMed
Summary
This summary is machine-generated.

Organic electrochemical transistors (OECTs) enable multi-valued logic circuits for advanced electronics. This study presents a novel dual-channel architecture for stable ternary logic states and high-speed operation.

Keywords:
electrochemical transistorsion penetrationmultivalued transistorsternary logicvertical transistors
