Identification and diagnosis of flow instability in parallel channel systems using machine learning.
Cheng Peng1, Xingchen Wang2, Runxin Tian2
1College of Energy and Mechanical Engineering, Shanghai University of Electric Power, Shanghai, China. diomio@shiep.edu.cn.
Communications Engineering
|May 15, 2026
Summary
Predicting density wave oscillations (DWOs) in thermal-fluid systems is crucial for safety. This study introduces an intelligent framework using Genetic Algorithm (GA) and K-Nearest Neighbors (KNN) for accurate DWO identification and prediction.
Area of Science:
- Thermal-fluid dynamics
- Computational intelligence
- System safety engineering
Background:
- Density wave oscillations (DWOs) pose significant operational risks in parallel thermal-fluid systems.
- Predicting these instabilities is essential for both forced and natural circulation systems.
Purpose of the Study:
- To develop and validate an intelligent framework for accurate identification of hazardous density wave oscillations.
- To analyze DWO patterns in open and closed circulation systems and identify critical operational regions.
Main Methods:
- Numerical modeling of open and closed circulation systems.
- Hybrid approach combining Genetic Algorithm (GA) optimization and K-Nearest Neighbors (KNN) classification.
- Validation against manual and signal analysis methods.
Main Results:
- The developed framework accurately identifies hazardous states with 99.19% overall accuracy.
- GA-optimized KNN model achieved 96.4-100% accuracy with strong generalization.
- Spatial non-uniformity of heat load distribution was identified as a key factor governing instability.
Conclusions:
- The intelligent framework is effective and reliable for practical engineering applications in predicting DWOs.
- Findings inform the development of differentiated safety strategies based on heat load distribution.
