Electric-field Control of Electronic States in WS2 Nanodevices by Electrolyte Gating
Published on: April 12, 2018
11.8K
Recent advances in long-term stable black phosphorus transistors.
Da Wan1, Hao Huang2, Zhongzheng Wang2
1School of Information Science and Engineering, Wuhan University of Science and Technology, Wuhan, 430081, China.
Nanoscale
|October 2, 2020
Summary
Black phosphorus (BP) offers unique electronic properties for next-generation devices. Enhancing BP
Area of Science:
- Materials Science
- Condensed Matter Physics
- Nanotechnology
Background:
- Atomically thin black phosphorus (BP) exhibits high charge carrier mobility and unique electronic properties.
- BP is a promising post-silicon material for low-power electronics and optoelectronics.
- The practical application of BP is hindered by its poor environmental stability.
Purpose of the Study:
- To review recent advancements in enhancing the stability of black phosphorus electronics.
- To identify opportunities and challenges in developing BP for next-generation nanoelectronics.
- To bridge the gap between BP's potential and its practical application in electronic devices.
Main Methods:
- Literature review of recent research on black phosphorus stability.
- Analysis of fabrication techniques for large-area BP transistors.
- Evaluation of strategies for improving the performance and reliability of BP-based devices.
Main Results:
- Recent works demonstrate the feasibility of improving BP stability through various methods.
- Progress has been made in fabricating large-area BP transistors with enhanced performance.
- Strategies for passivation and encapsulation are crucial for device longevity.
Conclusions:
- Enhancing the stability of black phosphorus is key to realizing its potential in nanoelectronics.
- Further research is needed to overcome challenges in large-scale manufacturing and long-term reliability.
- Black phosphorus holds significant promise for future low-power and high-performance electronic applications.
